TSD Series micro Hall effect joystick

Micro multi-axis Hall effect joystick

View technical specifications

Key features

Micro size
One or two axis
Hall effect sensing
Features M2 or M3 threaded shaft
IP67 above panel sealing
2.5 million lifecycles

About our TSD series Micro Hall effect joystick

The TSD Series is a micro, multi-axis Hall effect joystick purposely designed for uncrewed systems and robotics applications. Available with choice of M3 male or M2 or M3 female threading, the TSD Series allows users to easily adapt their own handle. The TSD Series is rated for over 2.5M actuations and features IP67 above panel sealing as standard.

Do you need this product for your next project?

Request a quotation today or leave your details to receive more information from one of our experts.

Talk to an expert

Product downloads

TSD Series micro hall effect joystick

Have it your way

Not exactly what you’re looking for? We offer standard products, but can also help you with a tailor-made or fully customized solution. Please contact us for advice or budgetary pricing.

Talk to an expert

Technical Specifications

Specification	Value
Angular travel:	30º total (15º each direction from center)
Expected life:	2.5 million operations
Centering:	Spring return
Mass/weight:	13 grams**
Maximum vertical load:	50 lbF`
Maximum horizontal load:	15 lbF***
Actuation force:	0.7 +/- 0.1N
Technology:	Hall effect sensor, single
Resolution:	12 bit
Supply voltage:	5.00VDC +/- 0.01VDC regulated transient free
Supply voltage tolerance:	5.00VDC +/- 0.25VDC
Supply current:	20mA max
Operating temperature:	-40ºC +85ºC
Storage temperature:	-40ºC +85ºC
Above panel sealing:	IP67*
